Front view of Niigata SPN63  machine

Niigata - SPN63PL-MIL-NII-1999-00001

Rs. 3,257,950
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 4-axis Niigata SPN63 horizontal machining center was manufactured in 1999. It features a Fanuc 16-M control, a table size of 630 x 630 mm, and can handle a table load of up to 1200 kg. The machine offers X, Y, Z travels of 1000 mm, 880 mm, and 800 mm respectively, and includes a rotary table. The spindle operates between 50 - 12000 rpm with a taper size of 50 and a large tool magazine holding 177 tools. Reach out for more information.

Overview

  • brand: Niigata
  • year: 1998
  • MODEL: SPN63
  • application type: Milling
  • Location: Poland
  • machine type: Machining centers (horizontal)
  • control unit brand: Fanuc

Technical Information - Niigata SPN63

Control Unit

  • Brand: Fanuc
  • Model: 16-M

Main drive

  • Spindle speed range: 50 - 12,000 1/MIN
  • Tool taper: 50

Movement

  • X-AXIS Movement: 1000 mm
  • Y-AXIS Movement: 880 mm
  • Z-AXIS Movement: 800 mm

Table

  • Outer length: 630 mm
  • Outer width: 630 mm
  • Table load: 1200 kg

Additional Information

    Machine Benefits

    • Technical Machine Benefits:
      • - Tool magazine: 177 tools
      • - High spindle speed, large tool magazine, rotary table for complex geometries.
    • Qualitative Machine Benefits:
      • - High precision and reliability with fanuc control.

    Extra information

    • - Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
