Huron - K2X 8 FivePT-MIL-HUR-2006-00002

Rs. 5,530,511
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 5-axis Huron K2X 8 Five gantry milling machine was manufactured in 2006. It features an impressive X-axis travel of 2,000 mm, Y-axis travel of 1,600 mm, and Z-axis travel of 1,100 mm. The machine includes a robust table size of 2,300 × 1,500 mm and a maximum table load of 4,000 kg. If you are looking to get high-quality milling capabilities, consider the Huron K2X 8 Five machine we have for sale. Contact us for further details.

Overview

  • brand: Huron
  • year: 2006
  • MODEL: K2X 8 Five
  • application type: Milling
  • Location: Portugal
  • machine type: Gantry Milling Machine

Technical Information - Huron K2X 8 Five

Dimensions

  • Table Load: 4000 kg

Movement

  • Number of Axes: 5
  • X-axis Travel: 650 mm
  • Y-axis Travel: 700 mm
  • Z-axis Travel: 450 mm

Technical Specification

  • Spindle Power: 30 kW
  • Spindle Speed: 18000 RPM
  • Tool Stations: 40

Additional Information

  • Simultaneous 5-axis machining

  • Rotary axis (B): ±110°

  • Rotary table axis (C): 360° continuous

  • Table size: 2,300 × 1,500 mm

  • Spindle taper: HSK-A63

  • Through-spindle coolant

Additional equipment

  • Chip conveyor

  • Portable MPG handwheel

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.

Your account manager:

Sergi Guardia

Sergi Guardia is one of our used machinery trading experts and will be your direct contact for any further questions on the machine. Feel free to contact him/her.

get in contact

Payment Terms

  • Payment in advance

  • Asset Financing
