DMG MORI - ecoTurn 450 V1DE-TUR-DMG-2016-00002
Do you have further questions? Contact us.

Alessandro Martini
+49 162 585 84 48
a.martini@gindumac.com

- GINDUMAC
- Products
- Machine Tools
- ➤ Used DMG MORI ecoTurn 450 V1 For Sale | gindumac.com
This DMG MORI ecoTurn 450 V1 horizontal turning machine was manufactured in 2016. It features a Siemens Sinumerik 840D control system, a maximum turning diameter of 400mm, and a rapid traverse rate of 30 m/min in both X and Z axes. The spindle supports a maximum speed of 4000 rpm, and the tool turret holds 12 stations. Consider the opportunity to buy this DMG MORI ecoTurn 450 V1 horizontal turning machine. Contact us for more information.
Overview
- brand: DMG MORI
- year: 2016
- MODEL: ecoTurn 450 V1
- application type: Turning
- Location: Germany
- machine type: Horizontal Turning Machine
- availability: Sold
- control unit brand: SIEMENS
Technical Information - DMG MORI ecoTurn 450 V1
General Data
- Machine weight: 5800 kg
Control Unit
- Brand: SIEMENS
Controller
- Brand: Siemens
- Model: Sinumerik 840D
Main drive
- Spindle speed range: 4000 rpm 1/MIN
Media
- Chip conveyor: Yes
Additional equipment
- - Hydraulic Unit Tank Capacity: 10 L / Max. Pressure: 55 bar
- - Coolant System Capacity: 170 L / Coolant Spray Gun: 5 bar
- - Mechanical Oil Separator Type: ASF 600 m³/h
- - machine has no driven tools
Additional Information
- Technical Machine Benefits:
- - Dimensions of machine (lxwxh): machine with chip tray 3000 x 2660 x 1932 mm; machine with chip conveyor approx. 4180 x 2660 x 1932 mm
- - Torque (40%/100% ed): 370 / 280 nm
- - Max. Swivel range over bed: 650 mm / swivel range over x carriage: 465 mm
- - Max. Turning diameter: 400 mm / max. Turning diameter with y-axis: 315 mm
- - Chuck diameter: 250/215 mm / travel x: 267. 5 mm / travel z: 600 mm / rapid traverse x/z: 30/30 m/min
- - Tool stations: 12 tool stations / tool holder: vdi 40 /cylinder shaft diameter: 40 mm / number of tool stations: bmt 6
- - Stroke: 500 mm
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
