Weeke - CE OPTIMAT BHC VENTURE 3 - LT-CNC-WEE-2002-00001

Rs. 2,120,481
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer

Do you have further questions? Contact us.

sales contact

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 3-axis Weeke CE OPTIMAT BHC VENTURE 3 was manufactured in 2002. It features a powerful 17 kW main motor and a maximum spindle speed of 24,000 rpm. The working field measures 3250 × 1250 × 1215 mm, with a rapid traverse speed of 100/50/20 m/min. Ideal for diverse CNC woodworking tasks, it also requires 7 bar of compressed air and has a dust extraction capacity of 3170 m³/h. Contact us for more information about this machine.

Overview

  • brand: Weeke
  • year: 2002
  • MODEL: CE OPTIMAT BHC VENTURE 3 -
  • application type: CNC Wood Machining
  • Location: Lithuania
  • machine type: CNC Wood Machining Centre

Technical Information - Weeke CE OPTIMAT BHC VENTURE 3 -

Dimensions

  • Machine Weight: 4300 kg

Movement

  • Number of Axes: 3
  • X-axis Travel: 3860 mm
  • Y-axis Travel: 1793 mm
  • Z-axis Travel: 185 mm

Technical Specification

  • Spindle Power: 17 kW
  • Spindle Speed: 24000 RPM

Additional Information

  • Electrical power: 400 V · 50 Hz · 3~+N · 17.5 kW · 35 A · 24 V

  • Milling spindle: 1 unit

  • Working field (X/Y/Z): 3250 × 1250 × 1215 mm

  • Rapid traverse speed (X/Y/Z): 100 / 50 / 20 m/min

  • Routing area: 3595 × 1378 × 125 mm

  • Alternative operation area: 1450 mm

  • Two-field operation area: 1100 mm

  • Compressed air required: 7 bar

  • Dust extraction (minimum): 3170 m³/h

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

Your account manager:

Alessandro Martini

Alessandro Martini is one of our used machinery trading experts and will be your direct contact for any further questions on the machine. Feel free to contact him/her.

get in contact

Payment Terms

  • Payment in advance

  • Asset Financing
