Biglia B545M

Photo Gallery

Biglia - B545MIT-TUR-BIG-2012-00001

Sold

Do you have further questions? Contact us.

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
BIGLIA B545M Lathe

Show in original language

This BIGLIA B545M Lathe was manufactured in the year 2012. It is equipped with a Fanuc Series 32i MODEL B control unit and has 4 axis. The machine has a spindle speed of 5000 rpm.

Overview

brand: Biglia
year: 2012
MODEL: B545M
application type: Turning
Location: Italy
machine type: Turn-Mill Centre
control unit brand: FANUC

Technical Information - Biglia B545M

Control Unit

Control Brand: FANUC
Control Model: Series 32i MODEL B

Dimensions

Machine Depth: 1901 mm
Machine Height: 2125 mm
Machine Weight: 4600 kg

Movement

C-axis: 0.001°
Number of Axes: 4
X-axis Travel: 170 mm
Z-axis Travel: 560 mm

Technical Specification

Spindle Power: 15 kW
Spindle Speed: 5000 RPM

Additional Information

Machine Benefits

Qualitative Machine Benefits

Hydraulic system
Lubrication system
Coolant system

Technical Machine Benefits

Max. Bar turning dia: 51 mm
Max. Turning dia: 290 mm
Constant power starting at: 1320 rpm
Max. Chuck dia. : 210 mm
Max. Longitudinal travel: 490 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
