Behringer - VMS 370 PVPL-SAW-BEH-2020-00001

Cutting capacity at 90°:

• Round: up to 130 mm diameter

• Square: up to 120 × 120 mm

• Flat: up to 200 × 100 mm

Cutting capacity at 45°:

• Round: up to 130 mm diameter

• Square: up to 100 × 100 mm

• Flat: up to 140 × 100 mm

Cutting capacity at 30°:

• Round: up to 105 mm diameter

• Square: up to 90 × 90 mm

• Flat: up to 100 × 100 mm

Saw blade diameter: 370 mm

Motor power: 2.0 / 2.6 kW

Saw blade speeds: 17 / 34 / 68 rpm

Optional saw blade speeds: 8 / 16 / 32 / 64 rpm

Saw feed: Hydro-pneumatic

Material clamping: Pneumatic

Mitre cutting range: -45° to +45°

Additional mitre angle: 30° on one side

Coolant system: Integrated

Material support height: 900 mm
