Hydraulic press manufactured in 2018. This Baykal APHS 31200 features a press force of 200 t and a bending length of 3,100 mm. With a maximum stroke of approximately 260 mm, it is designed for efficient bending operations. If you are looking to get high-quality bending capabilities, consider the Baykal APHS 31200 hydraulic press we have for sale. Contact us for further details.
Overview
- brand: Baykal
- year: 2018
- MODEL: APHS 31200
- production hours: 2154
- application type: Bending
- Location: France
- machine type: Hydraulic Press
Technical Information - Baykal APHS 31200
Dimensions
- Machine Height: 2890 mm
- Machine Length: 3580 mm
- Machine Weight: 11000 kg
- Machine Width: 1850 mm
Technical Specification
- Bending Length: 3100 mm
- Max. Stroke: 260 mm
- Pressing Force: 2000 Kn
Additional Information
Hydraulic pressure: approx. 276 bar
Nominal power: approx. 15.3 kW
Power supply: 400 V / 50 Hz / 3 Ph
Production hours: 2,154 h
Additional equipment
Included tooling:
V16 H80 mm: 10 / 15 / 20 / 40 / 50 / 100 / 200 / 370 / 835 ×2 mm
V50 H60 mm: 10 / 15 / 20 / 40 / 50 / 100 / 200 / 370 / 835 ×3 mm
V12 H80 mm: 10 ×2 / 15 / 20 / 195 / 285 / 295 / 835 ×3 mm
V80 H80 mm: 835 ×3 mm
V16 / V22 / V32 / V50: 10 / 15 / 20 / 40 / 50 / 100 / 200 / 370 / 835 ×3 mm
Additional tooling information:
ID 1177 – Standard – 85° – Height 65.50 mm – Radius 3.00 mm
ID 1271 – Standard – 60° – Height 115.00 mm – Radius 0.80 mm
ID 1284 – Standard – 60° – Height 135.00 mm – Radius 0.80 mm
TS-10.516 – Standard – 60° – Height 85.00 mm – Radius 0.80 mm
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
