➤ Used SKODA WEA 200 CNC For sale | gindumac.com

Show in original language

This 4-axis SKODA WEA 200 CNC boring machine was manufactured in 1983. It features a robust SIEMENS Sinumerik 840 C control system, extensive travel with X Axis at 13000 mm, Y Axis at 4150 mm, and Z Axis at 2000 mm. The table size is 3500 x 3500 mm, supporting a maximum workpiece weight of 60 tons. Additional equipment includes 4 milling heads. For more information about this boring machine, please reach out to us.

Overview

brand: SKODA
year: 1983
MODEL: WEA 200 CNC
application type: Other Machine Tools
Location: Czech Republic
machine type: Boring Machine (Metal)
availability: Sold
control unit brand: SIEMENS

Technical Information - SKODA WEA 200 CNC

General Data

Machine weight: 110000 KG

Control Unit

Model: Sinumerik 840 C
Brand: SIEMENS

Main drive

Tool taper: ISO 60

Movement

X-AXIS Movement: 13000 mm
Y-AXIS Movement: 4150 mm
Z-AXIS Movement: 2000 mm

Workpiece

Workpiece weight: 60 t KG

Table

Outer length: 3500 mm
Outer width: 3500 mm

Additional equipment

- 4 pcs milling heads
- Floor plates are not included

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Spindle diameter 200 mm
- - Quill size 520x520 mm

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
