TOS Varnsdorf - WHN130HU-OTH-TOS-2007-00001

Rs. 8,427,623
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer

Do you have further questions? Contact us.

sales contact

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 5-axis TOS Varnsdorf WHN130 was manufactured in 2007. It features a horizontal boring and milling machine with a table size of 1600 × 1800 mm and a spindle diameter of 130 mm. The machine includes a rotary table and is controlled by an NCT-104 system. Consider the opportunity to buy this TOS Varnsdorf WHN130 boring machine. Contact us for more information.

Overview

  • brand: TOS Varnsdorf
  • year: 2007
  • MODEL: WHN130
  • application type: Other Machine Tools
  • Location: Hungary
  • machine type: Boring Machine (Metal)

Technical Information - TOS Varnsdorf WHN130

Movement

  • Number of Axes: 5
  • X-axis Travel: 3500 mm
  • Y-axis Travel: 2000 mm
  • Z-axis Travel: 1220 mm

Additional Information

  • Control system: NCT-104

Spindle

  • Spindle diameter: 130 mm

  • Taper: ISO 50 (7:24)

  • Spindle speed range: 10 – 1500 rpm

  • Max spindle torque: approx. 2350 Nm

  • Main motor power: 37 kW

Axis Travels

  • X-axis travel: 3500 mm

  • Y-axis travel: 2000 mm

  • Z-axis travel: 1220 mm

  • W-axis (spindle quill travel): 570 mm

Table

  • Rotary table size: 1600 x 1800 mm

  • Max workpiece weight: 12,000 kg

  • T-slots: 22 x 9 x 160 mm

  • B-axis table feed: 0.03 – 1.5 rpm

Feed Rates

  • Rapid traverse (X / Y / Z / W): 2000 mm/min

Power

  • Total power requirement: approx. 80 – 83 kVA

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
