➤ Used KNUTH BO 110 For Sale | gindumac.com

Show in original language

This KNUTH BO 110 was manufactured in 2013. A robust boring machine, it features a maximum workpiece diameter of 250 mm and a grinding length of up to 500 mm. The grinding wheel operates at 1670 RPM, with a headstock speed variable from 50 to 500 RPM. It supports a table swivel range of ±9° and a table speed up to 4 m/min. Ideal for precision boring, the KNUTH BO 110 machine we have for sale. Contact us for further details.

Overview

brand: KNUTH
year: 2013
MODEL: BO 110
application type: Other Machine Tools
Location: Hungary
machine type: Boring Machine (Metal)

Technical Information - KNUTH BO 110

General Data

Machine weight: 1850 KG

Main drive

Spindle speed range: 1670 (Grinding Wheel), 50 - 500 (Headstock) 1/MIN
Number of axis: 2
Spindle motor power: 1.5 kW (Grinding Motor), 0.75 kW (Headstock Motor), 0.75 kW (Hydraulic Motor)
Tool taper: MT 3

Workpiece

Workpiece drm: 250 mm

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Center height: 125 mm
- - Grinding length (max): 500 mm
- - Distance between centers: 500 mm
- - Table swivel range: ± 9°
- - Table speed: 0. 1 - 4 m/min (infinitely adjustable)
- - Variable speed headstock
- - Infinitely adjustable table speed
- - Tailstock quill travel: 30 mm
- - Grinding wheel size (diameter x width x bore): 300 x 40 x 127 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
