This 3-axis SCM Record 240 was manufactured in 2001. It features a vertical main spindle and a vacuum table for workpiece fixation. The integrated extraction system ensures a clean working environment, while the Becker vacuum pump provides efficient performance with an inlet capacity of approximately 240 m³/h. If you are looking to get high-quality CNC wood machining capabilities, consider the SCM Record 240 machine we have for sale. Contact us for further details.
Overview
- brand: SCM
- year: 2001
- MODEL: Record 240
- production hours: 38809
- application type: CNC Wood Machining
- Location: Germany
- machine type: CNC Wood Machining Centre
Technical Information - SCM Record 240
Dimensions
- Machine Weight: 8000 kg
Movement
- Number of Axes: 3
Additional Information
Voltage: 400 V
Phase: 3 Phase
Frequency: 50 Hz
Current: 79 A
Workpiece Fixation: Vacuum Table
Main Spindle Type: Vertical Main Spindle
Dust Extraction: Integrated Extraction System
Hours: 38.809 h
Additional equipment
Vacuum Pump: Becker VTLF 2.250/1
Speed: 1440 rpm
Power Requirement: 5.4 kW
Inlet Capacity: approx. 240 m³/h
Maximum Vacuum: approx. 200 mbar
Extraction System: AL-KO
Power: 3.0 kW
Voltage: 400 V
Accessory: BENZ GmbH Angle Head / Angular Aggregate
Tool Holder Interface: HSK63
Transmission Ratio: 1:1
Maximum Input Speed: 12,000 rpm
Maximum Aggregate Speed: 12,000 rpm
Direction of Rotation: Right-hand rotation
Lubrication Type: Grease lubrication
Lubricant: Klüber Isoflex NBU15
Maximum Tool Torque: 20 Nm
Maximum Tool Diameter: 10 mm
Accessory Weight: approx. 5.5 kg
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
