IMA precision woodworking machine with dual monitors and control panels, front view showing conveyor and tooling area.
IMA precision woodworking machine with dual monitors and control panels, front view showing conveyor and tooling area.

IMA - NOVIMAT I /G80/390/R3DE-EDG-IMA-2013-00001

Rs. 2,020,922
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This IMA NOVIMAT I /G80/390/R3 edgebander was manufactured in 2013. It features dual 4.5 kW motors at 150 Hz, achieving speeds up to 9000 rpm. Capable of handling edge heights from 14 to 65 mm and roll diameters up to 850 mm, it's ideal for precise edgebanding needs. Consider the opportunity to buy this IMA NOVIMAT I /G80/390/R3 edgebander. Contact us for more information about this machine.

Overview

  • brand: IMA
  • year: 2013
  • MODEL: NOVIMAT I /G80/390/R3
  • application type: Edge Banding
  • Location: Germany
  • machine type: Edgebander

Additional Information

Additional information

  • Motor Power: 2 x 45 kW, 150 Hz

  • Motor Speed: 9000 rpm

  • Power Supply: 230 V

  • Heating Power: 6 x 500 watts

  • Adjustment Range: Vertical approx. 17 mm, Horizontal approx. 30 mm

  • Stroke: Max. 8 mm

  • Roll Diameter: Max. 850 mm

  • Edge Height: 14 – 65 mm

  • Workpiece Projection: Min. 30 mm + edge thickness, Max. 80 mm including edge thickness

  • Workpiece Length: Min. 130 mm

  • Workpiece Gap: Min. 300 mm

  • Workpiece Distance: Min. 990 mm

  • Workpiece Thickness: Min. 8 mm, Min. 12 mm with tracing wheel, Max. 80 mm

  • Single Tracing Workpiece Projection: Min. 30 mm

  • Double Tracing Workpiece Projection: Min. 38 mm for max. 4 profiles, Max. 50 mm

  • Cutter Head Diameter: 125 mm

  • Motor Shaft: 30 x 68 mm diameter

  • Internal Thread: M16, Depending on motor, left or right

  • Cutting Cross-section Motor Power: 0.20 kW, 200 Hz 400 V, 12000 rpm for max. 195 mm², Option: 0.66 kW, Extension to max. 1100 mm²

  • Tool Diameter: 160 mm / 48 teeth

  • Swivel Range: 0 and 25 degrees

  • Workpiece Speed: Max. 30 m/min for an edge cross-section of 3 x 45 mm

  • Edge Overhang: Top edge, max. 3 mm, Bottom edge, max. 2 mm for straight edges

  • Edge Material: Edge, max. 4 mm for wood and plastic; Aluminum, max. 3 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
