Gildemeister Twin 41

Photo Gallery

Gildemeister - Twin 41DE-TUR-GIL-2006-00002

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used Gildemeister Twin 41 For Sale | gindumac.com

Show in original language

This 7-axis Gildemeister Twin 41 horizontal turning machine was manufactured in 2006. Ideal for precision and complex turning operations, it offers robust performance and reliability. Consider the opportunity to buy this Gildemeister Twin 41 horizontal turning machine. Contact us for more information.

Overview

brand: Gildemeister
year: 2006
MODEL: Twin 41
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
control unit brand: SIEMENS

Technical Information - Gildemeister Twin 41

Control Unit

Control Brand: SIEMENS
Control Model: 840 D

Movement

Number of Axes: 7

Technical Specification

Spindle Speed: 7000 RPM

Additional Information

Additional equipment

Double spindle version
Y-axis
Main and counter spindle
Collet chuck
1 attached tool axial
1 attached tool radial
Belt filter system
Loading magazine FMB Turbo 10-72 XT

Machine Benefits

Technical Machine Benefits

Rotation diameter 145 mm
Chuck diameter (spindle 1 + 2): 140 mm
Longitudinal slide travel z1, z2, z3: 320 mm, 345 mm, 380 mm
Vertical slide travel y1: +/- 30 mm
Longitudinal spindle travel z3: 380 mm
Tool stations: 12, all stations attached
Shank diameter: 25 mm
Speed of the attached tools: 6000 rpm
C-axis: 2000 rpm
Pitch: 0. 001°

Extra Information

Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
