Front view of DMG MORI DMU 95 monoBLOCK  machine

DMG MORI DMU 95 monoBLOCK

DMG MORI - DMU 95 monoBLOCK

2019

Rs. 26,308,850

gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This DMG MORI DMU 95 monoBLOCK Universal Machining center was manufactured in the year 2019 in Germany. It is equipped with a CELOS HEIDENHAIN ITNC 640 ErgoLine control unit and has 5 axis. The machine has a spindle speed of 20000 rpm.

Overview

  • brand: DMG MORI
  • year: 2019
  • MODEL: DMU 95 monoBLOCK
  • application type: Milling
  • Location: Spain
  • machine type: Machining centers (universal)
  • availability: 01 06 2024
  • control unit brand: Celos Heidenhain
  • GINDUMAC ID: ES-MIL-DMG-2019-00001

Technical Information

General Data

  • Machine weight: 14000 kg

Control Unit

  • Brand: Celos Heidenhain
  • Model: TNC 640 ERGOline Touch

Main drive

  • Spindle speed range: 20000 1/MIN
  • Spindle motor power: 35 kW
  • Tool taper: SK 40
  • Number of axis: 5

Movement

  • X-AXIS Movement: 950 mm
  • Y-AXIS Movement: 850 mm
  • Z-AXIS Movement: 650 mm

Additional Information

    Extra information

    • - Motor spindle speedMASTER® 20,000 rpm 35 kW / 46.9 hp (40% duty cycle); 25 KW / 33.5 hp (100% duty cycle) Spindle taper SK 40 to DIN 69871 Tool clamping to DIN 69872 Vertical headstock Tool change system double gripper Chain magazine 60 magazine pockets SK 40 NC swivel rotary table Table plate C-axis: d 850 × 750 mm / 33.4 x29.5 in, integrated in rigid table 1,000 mm x 750 mm / 39.4 in x 29.5 in MPC Machine Protection Control Chip trough with integrated coolant tank 500 | / 132 gallon Celos With Heidenhain TNC 64021.5 " ERGOline Touch® Control with Multi-Touch-Screen Internal coolant supply 40bar / 23 l/min 3D quickSET

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
