Front view of Arburg 370C-800-350  machine

Arburg 370C-800-350

Arburg - 370C-800-350



Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

Click to chat on WhatsApp
Show in original language

This Arburg 370C-800-350 Injection moulding machine was manufactured in the year 2000 and has 102870 pump operating hours, of which 92471 are automatic operating hours. The machine has a clamping force of 800 kN and a screw diameter of 35 mm.


  • brand: Arburg
  • year: 2000
  • MODEL: 370C-800-350
  • production hours: 102870
  • application type: Injection Moulding
  • Location: Germany
  • machine type: Injection Moulding Machine
  • availability: Sold
  • GINDUMAC ID: DE-INJ-ARB-2000-00006

Technical Information

Injection Unit

  • Screw diameter: 35 mm
  • Injection pressure: 1823 bar

Clamping unit

  • Clamping force: 800 kN
  • Opening stroke: 500 mm

Additional Information

    Machine Benefits

    • Technical Machine Benefits:
      • - Min. Wkz installation height: 250 mm
      • - Clear tie bar spacing horizontal x vertical : 370x370 mm
      • - Centring ring Ø (ds/as) : 125/125 mm
      • - Max. Stroke volume (cm^3) 144
      • - Core pulls:1
      • - Hot runner control points: 3
      • - Handling: multilift

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
