MILLTRONICS - RH 20ES-MIL-MIL-2014-00001

Rs. 4,394,732
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer

Do you have further questions? Contact us.

sales contact

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 3-axis MILLTRONICS RH 20 vertical machining centre was manufactured in 2014. It features a substantial table size of 1,372 mm x 508 mm and impressive X-axis travel of 1,016 mm. The machine is equipped with a 24-station automatic tool changer and a spindle speed of 10,000 RPM. If you are looking to get high-quality machining capabilities, consider the MILLTRONICS RH 20 machine we have for sale. Contact us for further details.

Overview

  • brand: MILLTRONICS
  • year: 2014
  • MODEL: RH 20
  • application type: Milling
  • Location: Spain
  • machine type: Vertical Machining Centre

Technical Information - MILLTRONICS RH 20

Dimensions

  • Machine Weight: 6125 kg

Movement

  • Number of Axes: 3
  • X-axis Travel: 1016 mm
  • Y-axis Travel: 559 mm
  • Z-axis Travel: 610 mm

Technical Specification

  • Spindle Power: 18 kW
  • Spindle Speed: 10000 RPM
  • Taper Size: ISO 40

Additional Information

  • Table size: 1,372 mm x 508 mm (54" x 20")

  • Spindle nose to table: 102–711 mm (4"–28")

  • Spindle torque: 122 N·m (90 ft·lb)

  • Transmission: 2-speed torque range

  • Automatic tool changer: 24-station twin arm

  • Max tool diameter: 75 mm (3")

  • Max tool length: 300 mm (11.8")

  • Rapid traverse (X/Y/Z): 24/24/15 m/min (945/945/600 ipm)

  • Control system: Milltronics CNC with 15" color LCD

  • Power required: 30 kVA / 80 A

  • Voltage: 208–240 V, 3-phase

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

Your account manager:

Alessandro Martini

Alessandro Martini is one of our used machinery trading experts and will be your direct contact for any further questions on the machine. Feel free to contact him/her.

get in contact

Payment Terms

  • Payment in advance

  • Asset Financing
