Front view of Mazak Quick Turn Nexus 250-II MS machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

Mazak Quick Turn Nexus 200-II MS

Mazak - Quick Turn Nexus 200-II MSBG-TUR-MAZ-2008-00003

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
Mazak Quick Turn Nexus 200-II MS Lathe

Show in original language

This Mazak Quick Turn Nexus 200-II MS Lathe was built in the United Kingdom in 2008. It has 32919 hours of which 8882 are cutting hours. It is equipped with a Mazatrol Matrix Nexus control unit. It can works with a spindle speed up to 5000 rpm.

Overview

brand: Mazak
year: 2008
MODEL: Quick Turn Nexus 200-II MS
production hours: 8882
application type: Turning
Location: Bulgaria
machine type: Horizontal Turning Machine
availability: Sold
control unit brand: MAZATROL

Technical Information - Mazak Quick Turn Nexus 200-II MS

General Data

Measurements width: 1780 mm
Measurements depth: 2765 mm
Measurements height: 1840 mm
Machine weight: 5100 KG

Control Unit

Model: Matrix Nexus
Brand: MAZATROL

Main drive

Spindle speed range: 5000 1/MIN
Spindle motor power: 26 kW
Spindle bore: Ø 65 mm

Tools

Slots in storage: 12

Media

Main electronic connection: 3 x 400V / 50Hz
Power consumption: 46.9 kVA

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Cutting diameter: 276 / 380 mm
- - Number of power-driven tools: 12
- - Plan travel (x): 230 mm
- - Longitudinal travel (z): 575 mm
- - W-axis movement (counter spindle to main spindle): 585 mm
- - Minimum indexing of the main spindle of the c axis: 0. 0001°
- - Minimum indexing c-axis counter spindle: 0. 001°
- - Spindle speed driven tools: 4500 rpm
- - Spindle motor driven tools: 5. 5 kw
Qualitative Machine Benefits:
- - *tools included: 1 - rotating holder - radial
- - 2 - lathes for external processing
- - 2 - lathes for external processing
- - 4 - holder for fastening bushings with diameter ф32mm
- - 5 - lathes for external processing
- - 6 - rotating holder - axial
- - 7 - empty nest
- - 8 - lathes for external processing - double-sided
- - 9 - lathe fastening type dovetail
- - 10 - holder for fastening bushings with diameter ф32mm

Extra information

- Tools included: 11 - lathes - axial 12 - holder for fastening bushings with diameter ф32mm 13 - rotating holder - axial 14 - lathe - axial 15 - rotating holder - axial 16 - empty nest

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
