Front view of Mazak INTEGREX 300Y  machine

Mazak - INTEGREX 300YIT-TUR-MAZ-2001-00003

Rs. 4,635,200
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 5-axis Mazak INTEGREX 300Y horizontal turning machine was manufactured in 2001. It features a Mazatrol Fusion 640MT control, a maximum swing and workable diameter of 610 mm, and a milling spindle speed up to 6,000 rpm. The tool magazine holds 80 tools, enhancing productivity. Ideal for complex machining tasks, the Mazak INTEGREX 300Y machine we have for sale is robust and versatile. Contact us for further details regarding this horizontal turning machine.

Overview

  • brand: Mazak
  • year: 2001
  • MODEL: INTEGREX 300Y
  • application type: Turning
  • Location: Italy
  • machine type: Horizontal Turning Machine
  • availability: Immediately
  • control unit brand: MAZATROL

Technical Information - Mazak INTEGREX 300Y

General Data

  • Measurements width: 2718 MM
  • Measurements depth: 4850 MM
  • Measurements height: 2700 MM
  • Machine weight: 9110 KG

Control Unit

  • Model: FUSION 640MT
  • Brand: MAZATROL

Main drive

  • Spindle speed range: 35-3500 1/MIN
  • Tool taper: KM 63

Movement

  • X-AXIS Movement: 580 mm
  • Y-AXIS Movement: 210 mm
  • Z-AXIS Movement: 1605 mm

Media

  • Internal cooling: Yes

Additional Information

    Machine Benefits

    • Technical Machine Benefits:
      • - Cooling pressure: 70 bar
      • - Enhanced precision, versatile machining capabilities
      • - High/low tailstock sleeve pressure selection
      • - Piece size measurement system
      • - Positioning b-axis with minimum increment 0. 001°
      • - Camware expert for fusion 640mt
      • - Motor overload detector
      • - Preparation for "magnum 70bar" coolant system
      • - Synchronized tapping for motorized tools
      • - Breaker trip automatic shut-off
    • Qualitative Machine Benefits:
      • - Improved operational efficiency with automatic systems and robot interface
      • - N. 2 additional m functions
      • - Automatic opening/closing of front door (robot signal)
      • - Cylindrical interpolation (g07)
      • - Automatic opening/closing of self-centering clamps
      • - Optional "eia/iso" package
      • - Complete equipment with km 63 tool holders
      • - Linear scales on y axis
      • - Max swing 610 mm
      • - Max workable diameter 610 mm

    Extra information

    • - Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
