HAAS ST-30

Photo Gallery

HAAS - ST-30PL-TUR-HAA-2012-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used HAAS ST-30 Horizontal Lathe For Sale | gindumac.com

Show in original language

This HAAS ST-30 was manufactured in 2012. A robust horizontal turning machine featuring a spindle speed of 3400 rpm and motor power of 22.4 kW. It has a chuck size of 254 mm and a bar capacity of 76 mm, accommodating substantial workpieces. The machine dimensions are 4350 x 2290 x 2490 mm, weighing 4944 kg. Ideal for precision machining, the HAAS ST-30 machine we have for sale. Contact us for further details regarding this horizontal turning machine.

Overview

brand: HAAS
year: 2012
MODEL: ST-30
production hours: 4042
application type: Turning
Location: Poland
machine type: Horizontal Turning Machine
control unit brand: HAAS

Technical Information - HAAS ST-30

General Data

Measurements width: 2290 MM
Measurements depth: 4350 MM
Measurements height: 2490 MM
Machine weight: 4944 KG

Control Unit

Brand: HAAS

Main drive

Spindle speed range: 3400 1/MIN
Spindle motor power: 22.4 kW
Spindle bore: 88.9 mm
Tool taper: A2-6

Movement

X-AXIS Movement: 239 mm
X-AXIS Rapid traverse: 24 m/min
Z-AXIS Movement: 826 mm
Z-AXIS Rapid traverse: 24 m/min

Tools

Slots in storage: 12

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Turning length: 826 mm
- - Turning diameter: 381 mm
- - Max. Part swing: 533 mm
- - Distance between centers: 826 mm
- - Chuck size: 254 mm
- - Bar capacity: 76 mm

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
