➤ Used Bodor P3015 For Sale | gindumac.com

Show in original language

This 3-axis Bodor P3015 was manufactured in 2019 and is a robust fiber laser cutting machine. It features a 1.5 kW fiber laser, capable of cutting a variety of materials including carbon steel and aluminum, with a cutting area of 3000 mm x 1500 mm. It includes a Bodor CNC control system and an exchange table. If you are looking to get high-quality sheet metal cutting capabilities consider the Bodor P3015 machine we have for sale. Contact us for more information.

Overview

brand: Bodor
year: 2019
MODEL: P3015
application type: Cutting
Location: Hungary
machine type: Fiber Laser Cutting Machine
availability: Immediately

Technical Information - Bodor P3015

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Number of axes: 3 / cutting area (x x y): 3000 mm x 1500 mm / positioning accuracy: ±0. 03 mm / repeat positioning accuracy: ±0. 02 mm / max cutting speed: up to 60 m/min / supported materials: carbon steel, stainless steel, aluminum, brass, copper
- - Control system: cnc control system / software: operating system, compatible with common cad/cam formats
- - Laser type: fiber laser / laser power: 1. 5 kw
- - Maximum z-axis travel: typically 100 mm (depending on model)
- - Table type: exchange table (depending on configuration)
- - Power supply: 400v / 50hz / total power consumption: approx. 2030 kw (depending on model and auxiliary systems) / cooling system: water cooling (chiller) / assist gas: oxygen, nitrogen, air
- - Weight (kg): approx. 60008000 kg

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
