Front view of Universal Robots UR10 (2021) machine
Front view of Universal Robots UR10 (2021) machine

Universal Robots - UR10DE-ROB-UNI-2021-00001

Rs. 2,260,850
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 6-axis Universal Robots UR10 was manufactured in 2021, featuring a payload capacity of 10 kg and a reach of 1300 mm. It offers six rotating joints, operates within an ambient temperature range of 0−50°C, and has a noise level of 72dB(A). The robot can be mounted in any position and is IP54 rated, suitable for ISO Class 5 cleanrooms. If you are looking to get high-quality automation capabilities consider the Universal Robots UR10 machine we have for sale. Contact us for more information.

Overview

  • brand: Universal Robots
  • year: 2021
  • MODEL: UR10
  • application type: Robotics
  • Location: Germany
  • machine type: Robot Arm

Technical Information - Universal Robots UR10

Dimensions

  • Machine Weight: 28.9 kg

Movement

  • Number of Axes: 6

Additional Information

  • Reach: 1300 mm / 51.2 in

  • Degrees of freedom: 6 rotating joints

  • Repeatability: ±0.1 mm / ±0.0039 in (4 mils)

  • Ambient temperature range: 0–50 °C

  • Noise: 72 dB(A)

  • Robot mounting: Any

  • IP classification: IP54

  • ISO cleanroom class: 5

  • Footprint: Ø190 mm

  • Materials: Aluminium, PP plastics

  • Tool connector type: M8

  • Cable length: 6 m / 236 in

  • I/O ports: 2 digital in, 2 digital out, 2 analog in, 0 analog out

  • I/O power supply (tool): 12 V / 24 V, 600 mA

Joint ranges and max speeds (as provided)

  • Base: ±360°, ±120°/s

  • Shoulder: ±360°, ±120°/s

  • Elbow: ±360°, ±180°/s

  • Wrist 1: ±360°, ±180°/s

  • Wrist 2: ±360°, ±180°/s

  • Wrist 3: ±360°, ±180°/s

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
