Reis Robotics Laserroboter RV6L

Show in original language

This Reis Robotics Laserroboter RV6L robot was built in the year 2017 in Germany. This machine has a weight processing optics of 6 kg and a repeatability +- 0.05 mm.

Overview

brand: Reis Robotics
year: 2017
MODEL: Laserroboter RV6L
application type: Robotics
Location: Germany
machine type: Robot Arm
availability: Sold

Technical Information - Reis Robotics Laserroboter RV6L

General Data

Machine weight: 960 kg

Media

Power consumption: 7.1 kva

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Max. Weight processing optics / process accesories: 6k
- - Additional load a3 incl. Process-specific installation: 10 kg
- - Max. Weight laser: 400 kg
- - Axis data: axis a1 140 °/s; axis a2 105 °/s; axis a3 200 °/s; axis a4 700 °/s; axis a5 750 °/s
- - Repeatability: +- 0. 05 mm
- - Mains fusing: max. 3 x 25a

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
