Okuma MILLAC 800VH
Okuma - MILLAC 800VH
2009
Rs. 38,187,800
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF
Do you have further questions? Contact us.
Alessandro Martini
+49 162 585 84 48
a.martini@gindumac.com
Click to chat on WhatsApp
- GINDUMAC
- Products
- Machine Tools
- OKUMA MILLAC 800VH Vertical Machining center
Show in original language
This OKUMA MILLAC 800VH Vertical Machining center was manufactured in the year 2009. It is equipped with an Okuma P200 M control unit and has 5 axis. The machine has a spindle speed of 10000 rpm.
Overview
- brand: Okuma
- year: 2009
- MODEL: MILLAC 800VH
- production hours: 8890
- application type: Milling
- Location: Italy
- machine type: Machining centers (vertical)
- availability: Immediately
- control unit brand: Okuma
- GINDUMAC ID: IT-MIL-OKU-2009-00001
Technical Information
Control Unit
- Brand: Okuma
- Model: OSP P200 M
Main drive
- Spindle speed range: 10000 1/MIN
- Spindle motor power: 18,5/22 KW
- Number of axis: 5
Movement
- X-AXIS Movement: 1020 mm
- Y-AXIS Movement: 1020 mm
- Z-AXIS Movement: 1020 mm
Table
- Outer length: 800 mm
- Outer width: 800 mm
- Table load: 1000 kg
Additional Information
- Technical Machine Benefits:
- - Automatic palletization at 6 positions including 4 additional pallets
- - Tool magazine with 120 positions
- - Optical scales on linear axes x, y, z in addition to the std encoders.
- - Circular optical scale on spindle tilting head axis with 0. 001 g.
- - Resolution with tilting locking by means of brake
- - Circular optical scale on rotary table c axis
- - Resolution 0. 001 g. With continuous locking by brake
- - Measuring probe taken from tool changer for resetting/checking the workpiece including macro b on the cnc
- - Air blow for chips cleaning both around the spindle and for cleaning the cone flange bt 50
- - Laser probe for checking blum/laser diameter and tool length with pneumatic system for cleaning laser beam lenses
- Qualitative Machine Benefits:
- - Lubrication system through the spindle center at 70 bar 13/18 lt. /min. (6. 9 mpa) with in-line centrifugal filter
- - Air/coolant blow through selectable spindle
- - Shower washing system
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
