➤ Used Mazak Quick Turn Nexus 350-II M | Horizontal Lathe

Show in original language

This 2-axis Mazak Quick Turn Nexus 350-II M was manufactured in 2007. Ideal for precision horizontal turning, this machine maintains robust functionality. A solid choice for enhancing your machining capabilities. Contact us for more information about this machine.

Overview

brand: Mazak
year: 2007
MODEL: Quick Turn Nexus 350-II M
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
control unit brand: MAZATROL

Technical Information - Mazak Quick Turn Nexus 350-II M

Control Unit

Control Brand: MAZATROL
Control Model: MATRIX NEXUS

Dimensions

Machine Depth: 4190 mm
Machine Height: 2000 mm
Machine Weight: 7705 kg

Movement

Number of Axes: 2

Technical Specification

Spindle Speed: 3300 RPM

Additional Information

Additional equipment

Power transformer for the European market
Hydraulic 3-jaw chuck (OD 315 mm), Hollow clamping device with material passage 102 mm
Coolant and chip protection with fully enclosed work area
Work area lighting
Double foot switch
Automatic cutting data transfer (VFC)
Manual tool path memory function (TPS)
Machining navigation prediction, monitoring, and result
Preparation for chip conveyor attachment, rear ejection
Automatic tool presetting device (Tool Eye)

Machine Benefits

Technical Machine Benefits

Fast and precise production of threads by synchronising the milling spindle with the feed axis
Simplified input of angular coordinates for turning operations
Bed length: 1500 mm
Opening in chuck: 102 mm / max. Chuck size: hydr 3-jaw chuck
High-pressure coolant system (5 bar)
Belt oil skimmer
Chip conveyor lateral ejection (hinged belt version) / coolant tank 195kg, chip conveyor 500kg
Cnc-controlled lathe
Version: u1500
Kitagawa b212 a11-15x (od 315 mm) / max. Spindle bore: hollow clamping device with material passage 102 mm

Extra Information

Control Unit MAZATROL MATRIX NEXUS control system Large 12.1’ LCD color screen User macro (600 variables) EIA-ISO input function Tool path check in the background USB interface (2 pieces) LAN interface Intelligent heat shield Intelligent danger shield Mazak voice support (Voice Adviser) Virtual machining Turret 12-position tool turret Tail Stock Fully programmable tailstock Tailstock pressure regulation: 10 steps Tailstock with running quill MK5

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
