FANUC ROBODRILL α-T14iB

Photo Gallery

FANUC - ROBODRILL α-T14iBIT-MIL-FAN-1997-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used FANUC ROBODRILL α-T14iB For Sale | gindumac.com

Show in original language

This 3-axis FANUC ROBODRILL α-T14iB was manufactured in 1997. It features an X-axis travel of 500 mm, Y-axis travel of 400 mm, and Z-axis travel of 330 mm. The machine has a maximum spindle speed of 8,000 rpm and a tool changer capacity of 14 tools. If you are looking to get high-quality machining capabilities, consider the FANUC ROBODRILL α-T14iB vertical machining centre we have for sale. Contact us for further details.

Overview

brand: FANUC
year: 1997
MODEL: ROBODRILL α-T14iB
application type: Milling
Location: Italy
machine type: Vertical Machining Centre
control unit brand: FANUC

Technical Information - FANUC ROBODRILL α-T14iB

Control Unit

Control Brand: FANUC
Control Model: Series 16i-M

Dimensions

Table Load: 250 kg

Movement

Number of Axes: 3
X-axis Travel: 500 mm
Y-axis Travel: 400 mm
Z-axis Travel: 330 mm

Technical Specification

Spindle Speed: 8000 RPM
Taper Size: BT 30
Tool Stations: 14

Additional Information

Rapid feeds (X/Y/Z): up to 48 m/min
Installed power: 10 kVA
Supply: 200–220 V, 50/60 Hz, 3-phase
Registered cutting time: 15,291 h

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
