DMG - DMC80U DuoBlockAT-MIL-DMG-2011-00001

• Control: Heidenhain iTNC 530 3D path control

• B-axis Travel: 180° (Universal milling head with controlled B-axis)

• Spindle Type: Integrated motor spindle without gearbox

• Spindle speed ranges:

  • Operating mode 1: 0–10,000 rpm

  • Operating mode 2: 0–800 rpm

  • Operating mode 3: 0–5,000 rpm

• Spindle performance:

  • Spindle Power (40% Duty Cycle): 28 kW

  • Spindle Power (100% Duty Cycle): 19 kW

• Spindle hours: 34,062 h

• Machine on hours: 79,252 h

• Spindle: New spindle installed end of 2025

• Table Type: NC rotary table with pallet carrier

• Pallets Included: 2 pallets

• Pallet Clamping Surface: 800 mm x 630 mm

• Pallet T-slots: 14 mm per DIN 55201-A2

• Pallet Weight: 300 kg per pallet

• Maximum Permissible Workpiece Weight on Pallet: 1,400 kg

• Maximum Workpiece Height: 1,330 mm

• Maximum Workpiece Diameter: 900 mm

• Feed Rate (X/Y/Z): 0 - 60,000 mm/min

• Axis Acceleration (X/Y/Z): 7 / 6.5 / 6.5 m/s²

• Maximum Feed Force (X/Y): 13 kN

• Maximum Feed Force (Z): 9 kN

• Linear Scale Resolution (X/Y/Z): 0.001 mm

• Table Max Torque (40% duty cycle): 5,000 Nm

• Table Holding Torque (40% / 100% duty cycle): 5,000 Nm / 3,660 Nm

• Table Maximum Rotation: 35 rpm

• Pallet Changer Type: Rotary pallet changer

• Measuring Probe: Heidenhain TS 649 DMG Infrared probe

• Kinematics Verification: 3D quickSET toolkit

• Chip Management: Chip conveyor

• Mist Extraction System: Oil and emulsion mist extraction system with mechanical filter (1,600 m³/h flow rate)

• Cooling Capacity (Machine / Cabinet): 3.3 kW / 1.0 kW

• Electrical Connection Data: 86 kVA, 400 V, 50 Hz, Max Nominal Current 124 A

• Workpiece dimensions (max): Diameter 800 mm, height 600 mm

• Feed force (X/Y/Z): 10 kN

• Rapid traverse: 60 m/min

• Tool Holder Taper: SK 50 per DIN 69871 Form AD / Form B

• Tool Clamping Pull Stud: DIN 69872 Form A / Form B or ISO 7388/2 Typ B

• Tool Clamping Mechanism: Mechanical via spring force, hydraulic release

• Tool Magazine Capacity: 120 slots (vertical chain magazine)

• Delivery: January 2027

Additional equipment

• Dual pallet changer system

• Internal coolant supply (ICS) with 980 l tank and band filter (40 bar through spindle center)

• Clamping hydraulics

• Infrared measuring probe
