AGIE CUT CLASSIC V2

AGIE - CUT CLASSIC V2PT-EDM-AGI-2007-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
AGIE CUT CLASSIC V2 Erosion machine

Show in original language

This AGIE CUT CLASSIC V2 Erosion machine was manufactured in the year 2007 in Switzerland. It is equipped with 4 axis. The machine has a standard spool size of 25 kg. It is refurbished, in perfect condition and like new.

Overview

brand: AGIE
year: 2007
MODEL: CUT CLASSIC V2
application type: EDM
Location: Portugal
machine type: Wire EDM Machine
availability: Sold

Technical Information - AGIE CUT CLASSIC V2

General Data

Measurements width: 2040 mm
Measurements depth: 1640 mm
Measurements height: 2220 mm
Machine weight: 2680 kg

Main drive

Number of axis: 4

Movement

X-AXIS Movement: 350 mm
Y-AXIS Movement: 250 mm
Z-AXIS Movement: 256 mm
V-Axis Movement: (+-) 70 mm
U-Axis Movement: (+-) 70 mm

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Max. Part dimension: 750x550x250mm
- - Max. Weight part: 450 kg
- - Dielectric volume: 750 l
- - Standard spool size: 25 kg
- - Awt (automatic wire threading): yes
- - Standard wire guides: 0,25 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
