Rainer 1000R Punching Machine

Show in original language

This Rainer 1000R Punching Machine was manufactured in 1997 in Italy. It has been working for only 19106 hours. Equipped with a Rainer 1000 T2 control unit. This machine can operate with a punching force of 200 kN.

Overview

brand: Rainer
year: 1997
MODEL: 1000R
production hours: 19106
application type: Punching
Location: Croatia
machine type: Turret Punch Press

Technical Information - Rainer 1000R

General Data

Measurements width: 3500 mm
Measurements depth: 3900 mm
Measurements height: 2400 mm
Machine weight: 9500 kg

Control Unit

Model: 1000 T2
CNC main language: English

Main drive

Punching force: 200 kN
Maximum sheet thickness: 6,4 mm

Movement

X-AXIS Movement: 1270 mm
Y-AXIS Movement: 1000 mm

Workpiece

Workpiece weight: 50 kg

Tools

Number of index: 2
Number of stations: 1
Slots in storage: 19

Max Material thickness

Steel: 6,4 mm

Media

Main electronic connection: 380 V
Power consumption: 14 kVA

Additional Information

Machine Benefits

Technical Machine Benefits

Set of tools – 15 pcs
Flexible for batch work
Have repositioning

Machine History

Industries

Furniture

End product

Tables, furnaces

Material type

Steel, stain steel1,5 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
