Right view of Murata Wiedemann C-2000 machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

Murata Wiedemann C-2000

Photo Gallery

Murata Wiedemann - C-2000IN-PUN-MUR-1989-00001

Sold

Do you have further questions? Contact us.

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Sheet Metal Machinery
➤ Murata Wiedemann C-2000 Turret Punching Machine - Used

Show in original language

This Murata Wiedemann C-2000 Turret Punching Machine was manufactured in 1989 and has since then gathered a production record of 67200 working hours. This machine is equipped with an user friendly FANUC OP Control unit that offers 114 different tooling styles for its low-noise production work. This compact equipment, that also has a low maintenance cost, has worked mostly on up to 4 mm thick mild steel in the past, and includes a 15x Toolset as additional equipment.

Overview

brand: Murata Wiedemann
year: 1989
MODEL: C-2000
production hours: 67200
application type: Punching
Location: India
machine type: Turret Punch Press
availability: Sold
control unit brand: FANUC

Technical Information - Murata Wiedemann C-2000

General Data

Measurements width: 2800 mm
Measurements depth: 3800 mm
Measurements height: 1900 mm
Machine weight: 8000 kg

Control Unit

Brand: FANUC
Model: OP

Main drive

Punching force: 200 kN
Maximum sheet thickness: 4 mm

Movement

X-AXIS Movement: 1250 mm
Y-AXIS Movement: 1000 mm

Tools

Number of index: 2
Number of stations: 22
Max tool diameter: 75 mm

Max Material thickness

Steel: 4 mm
Stainless steel: 2 mm
Aluminum: 2 mm

Media

Main electronic connection: 415 V
Power consumption: 15 kVA
Air pressure: 6 bar

Additional equipment

- 15x Toolset

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
