Profile bending machine manufactured in 1993. This Müller Profilierung 3 features a maximum strip width of 300 mm and can handle material thicknesses up to 8 mm. It includes 13 forming stands on interchangeable plates and 4 hydraulic punching units. If you are looking to get high-quality profile bending capabilities, consider the Müller Profilierung 3 machine we have for sale. Contact us for further details.
Overview
- brand: Müller
- year: 1993
- MODEL: Profilierung 3
- application type: Rolling
- Location: Germany
- machine type: Profile Bending Machine
Technical Information - Müller Profilierung 3
Technical Specification
- Max. Sheet Thickness: 8 mm
- Rolling Diameter: 100 mm
Additional Information
- Maximum Strip Width: 300 mm
- Maximum Material Thickness: 8 mm
- Forming Stands: 13 stands (on 3 interchangeable plates / cassettes) according to technical specs; 14 stands with interchangeable plates according to text message
- Shaft Diameter: 100 mm
- Punching Units: 4 hydraulic punches
- Operating Mode: Start / Stop
- Interchangeable Cassettes / Pallets: 3 interchangeable pallets present
- Tooling / Accessories: Roller sets and tools
- Integrated Line Components: Decoiler / coil reel unit with hold-down arm, in-line hydraulic pre-punching station, roll forming cassette line with cardan drives, and automated stacking / pack basket station for finished profiles
