Front view of MARKFORGED Metal X  machine

MARKFORGED Metal X

MARKFORGED - Metal X

2018

Rs. 5,538,400

gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Alessandro Martini

+49 162 585 84 48

a.martini@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This MARKFORGED Metal X 3D Printer was made in 2018.

Overview

  • brand: MARKFORGED
  • year: 2018
  • MODEL: Metal X
  • application type: 3D Printing
  • Location: Norway
  • machine type: 3D Printer
  • availability: Immediately
  • GINDUMAC ID: NO-3DP-MAR-2018-00001

Technical Information

General Data

  • Measurements width: 575 mm
  • Measurements depth: 467 mm
  • Measurements height: 1120 mm
  • Machine weight: 75 kg

Additional Information

    Machine Benefits

    • Technical Machine Benefits:
      • - A wash-1 washing station for debinding
      • - In addition a gas handling system.
      • - A sinter-2 for sintering. The sinter-2 is the larger sintering oven from markforged.
      • - The sintering oven has run 7 times, and the printer has rundt 20-30 builds.
      • - External dimensions: 1,200 x 700 x 1,500 mm
      • - Bound powder filament
      • - 85 μm - 170 μm (post-sinter)
      • - Z layer resolution
      • - Heated, auto leveling, replaceable print sheets
      • - Internal part geometry
    • Qualitative Machine Benefits:
      • - Printing media
      • - Metal fff
      • - Closed cell infill (triangular) or solid parts
      • - Mage of wash-1 external dimensions: 609 x 685 x 1,067 mm
      • - Print bed
      • - Washing time: 12-72 hrs typical
      • - Wash-1 i weight: 136 kg (300 lbs)
      • - Working volume: 356 x 254 x 203 mm
      • - Printing process
      • - Wash & sinter

    Extra information

    • - Solvent: Opteon SF-79 Sinter-2 image of Sinter-2 Weight: 350 kg (772 lbs) Run Time: 17-31 hours Sintering Volume: 18,356 cu cm Peak Internal Temp.: 1,300° C / 2,372° F

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
