Kekeisen UFF 5000 Milling Machine

Show in original language

This Kekeisen UFF 5000 Milling Machine was manufactured in 1995 in Germany and has a working record of 38214 hours since then. Equipped with a SIEMENS SINUMERIK 840C Control unit, this stable machine can operate with a spindle speed up to 2000 rpm. It stands out for its universal milling head, that can work with vertical and horizontal.

Overview

brand: Kekeisen
year: 1995
MODEL: UFF 5000
production hours: 38214
application type: Milling
Location: Austria
machine type: Universal Machining Centre
control unit brand: SIEMENS

Technical Information - Kekeisen UFF 5000

General Data

Measurements width: 8200 mm
Measurements depth: 4000 mm
Measurements height: 4300 mm
Machine weight: 31000 kg

Control Unit

Model: SINUMERIK 840C
CNC main language: German
CNC language customizable: Yes
Brand: SIEMENS

Main drive

Number of spindles: 1
Spindle speed range: 2000 rpm 1/MIN

Movement

X-AXIS Movement: 5000 mm
Y-AXIS Movement: 1525 mm
Z-AXIS Movement: 1400 mm
C-AXIS Movement: round table - endless

Workpiece

Workpiece drm: 1740 mm
Workpiece x: 5000 mm
Workpiece y: 1525 mm
Workpiece z: 1400 mm
Workpiece weight: 12000 kg

Table

Outer length: 2500 mm
Outer width: 1250 mm
Number of tslots: 8x22H7
Distance between: 130 mm

Tools

Slots in storage: 40
Type of tool holder: SK50 Din 69871

Media

Main electronic connection: 400 V
Power consumption: 50 kVA
Chip conveyor: Yes
Internal cooling: Yes

Additional Information

Machine Benefits

Technical Machine Benefits

Cnc round table = 4 full axes
Automatical universal milling head horicontal/vertical moveable

Extra Information

The machine is equipped with a SINUMERIK 840C - CNC-3D-Interpolation, graph simulation, 486 DX2, Mainboard 5MB, 4 axes steering

Machine History

Industries

Power generation, petrochemical

End product

Power gneration parts

Material type

Stainless steel, steel

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
