Robot arm manufactured in 2018. This Hyundai Hi 5a-S features 16 simultaneous controlled axes, offering advanced programming and playback capabilities. It includes a full digital servo system and a user-friendly teach pendant with a 7" color TFT-LCD touch panel. The machine comes with a special gripper and a robust support podium. If you are looking to get high-quality automation capabilities, consider the Hyundai Hi 5a-S robot arm we have for sale. Contact us for further details.
Overview
- brand: Hyundai
- year: 2018
- MODEL: Hi 5a-S
- application type: Robotics
- Location: Italy
- machine type: Robot Arm
Additional Information
Control model: Hi5a-S
Number of controlled axes: 16 simultaneous
Operations: Programming and Playback
Interpolations: PTP, Linear, Circular
Position control: Serial Absolute Encoder
Memory/backup: USB or Ethernet
Servo system: Full digital servo
Interface: Native DeviceNet, 2x Ethernet, 2x RS232/RS422, 1x USB, 1x CAN (optional), 1x DeviceNet Master, 1x SD card
Dimensions: 700 × 900 × 630 mm
Teach pendant: TP520 (7" color TFT-LCD touch panel, Windows CE)
Compliance: CE Declaration of Conformity and manuals included
Additional equipment
Robot support podium (machined base ready for floor fixing)
Special gripper with spring-suspended suction cups and autonomous vacuum generator
Removable “claws” for tray handling
Industry 4.0 cyber-physical system (remote monitoring / tele-assistance)
Pro-face 7" color touch panel for production monitoring
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
