➤ Used HEESEMANN LSM 8 For Sale | gindumac.com

Show in original language

This HEESEMANN LSM 8 belt sander was manufactured in 2002. It features a sanding width of 1300 mm and accommodates workpiece thickness from 3 to 80 mm. Equipped with a vacuum transport belt and variable feed speed of 5–25 m/min, it ensures efficient material handling and flexibility in sanding operations. Consider the opportunity to buy this HEESEMANN LSM 8 belt sander. Contact us for more information about this machine.

Overview

brand: HEESEMANN
year: 2002
MODEL: LSM 8
application type: Sanding
Location: Romania
machine type: Belt Sander

Technical Information - HEESEMANN LSM 8

General Data

Measurements width: 2300 mm
Measurements depth: 3850 mm
Measurements height: 2500 mm
Machine weight: 9200 kg

Additional Information

Sanding width: 1300 mm
Workpiece thickness (hollow height): 3–80 mm
Belt conveyor feed speed: 5–25 m/min (variable)
Vacuum transport belt with vacuum unit: 7.5 kW
Feed motor power: 3 kW
Aggregates:
- Aggregate 1: Transversal sanding belt with electronic sectioned pad; belt 5400 × 150 mm; motor 13 kW; speed 12–24 m/s
- Aggregate 2: Longitudinal sanding belt with electronic sectioned pad; belt 1350 × 2620 mm; motor 16.5 kW; speed 10–20 m/s
- Aggregate 3: Longitudinal sanding belt with electronic sectioned pad; belt 1350 × 2620 mm; motor 16.5 kW; speed 10–20 m/s
- Aggregate 4: Brush cleaning unit
Total electrical load: 110 kW
Grinding band dimension: 1300 mm
Delivery condition: FCA Sovata, loaded on truck

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
