DAVI MCB E20 Hygraulic Plate Roll Bending machine

Show in original language

This DAVI MCB E20 Hygraulic Plate Roll Bending machine was manufactured in the year 2021 in Italy. The machine has a Rolling speed of 6 m/min and a Max material thickness of 26 mm.

Overview

brand: Davi
year: 2021
MODEL: MCB E20
application type: Bending
Location: Latvia
machine type: Roll Bending Machine

Technical Information - Davi MCB E20

Dimensions

Machine Depth: 1600 mm
Machine Height: 1540 mm

Technical Specification

Pressing Force: 6500 Kn

Additional Information

Machine Benefits

Qualitative Machine Benefits

Rolling speed 6 m/min
Installed power hp 25 (energy saving technology)

Technical Machine Benefits

Number of rolls: 4
Full hydraulic plate roll
Equipped with the following optional accessories: surface hardened rolls, cone rolling package, emergency safety system, davi 'iroll easy' control
The machine is complete with instruction manual
Ec declaration of conformity
Rolls length / free access 2050 mm.
Top roll diameter 290 mm
Less deflecting thanks to planetary guide technology.
Bottom roll diameter 270 mm
Side rolls diameter 210 mm.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
