CHARMILLES - ROBOFORM 350ES-EDM-CHA-2007-00001

Name: CHARMILLES ROBOFORM 350
Brand: CHARMILLES
SKU: ES-EDM-CHA-2007-00001
Price: 2424550 INR
Availability: InStock

Rs. 2,424,550

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used CHARMILLES ROBOFORM 350 For Sale | gindumac.com

Show in original language

This 3-axis CHARMILLES ROBOFORM 350 was manufactured in 2007. It features a CNC control with a graphical user interface and optional C-axis for tool changes. The machine accommodates workpieces up to 500 kg, with a dielectric system capacity of around 400 liters. If you are looking to get high-quality die-sinking capabilities, consider the CHARMILLES ROBOFORM 350 machine we have for sale. Contact us for more information about this machine.

Overview

brand: CHARMILLES
year: 2007
MODEL: ROBOFORM 350
application type: EDM
Location: Spain
machine type: Die-Sinking EDM Machine
availability: Immediately

Technical Information - CHARMILLES ROBOFORM 350

General Data

Measurements width: 1550 mm
Measurements depth: 1750 mm
Measurements height: 2300 mm
Machine weight: 2300 kg

Main drive

Number of axis: 3

Movement

X-AXIS Movement: 350 mm
Y-AXIS Movement: 250 mm
Z-AXIS Movement: 300 mm

Workpiece

Workpiece weight: 500 kg

Additional equipment

- Tool Changer (C-axis): Optional – can support automatic tool changers
- Dielectric System Capacity: Approx. 400 liters

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Worktank dimensions (lxwxh): 790 x 530 x 350 mm
- - Max. Workpiece dimensions (lxwxh): 790 x 530 x 215 mm
- - Table dimensions (lxw): 500 x 400 mm
- - Distance from table to chuck: 170 to 470 mm
- - Tool electrode weight (max. ): 50 kg
- - Cnc control: charmilles cnc with graphical user interface

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
