WALTER - HELITRONIC RAPTOR DIAMONDPL-GRI-WAL-2023-00001

• Operating hours: approx. 4,371 h

• Working range:

  • Tool diameter: Ø3–290 mm (optional up to Ø400 mm, depending on configuration)

  • Maximum tool length: 270 mm (optional up to 350 mm, depending on configuration)

  • Maximum tool weight: 50 kg

• Axes:

  • Number of CNC axes: 5

  • Linear axis speed: up to 15 m/min

• Spindle:

  • Max grinding wheel diameter: Ø200 mm

  • Interface: HSK

  • Belt-driven, double-ended spindle

• Grinding / Eroding:

  • Grinding and EDM in one setup

  • For carbide, HSS, PCD, CBN tools

  • Configurable for up to 3 electrodes and 3 grinding wheels, or alternatively up to 6 grinding wheels

• Control / Machine design:

  • WALTER / UNITED GRINDING CNC control

  • Enclosed working area with automatic protective door

Additional equipment

• Automatic loading/manipulator system for shank tools (automatic tool loader/manipulator)

• Process cooling system

• Coolant/dielectric filtration and circulation system

• Coolant/dielectric system

• Tool holders

• Flanges/adapters

• Grinding wheel/electrode accessories
