VOUMARD - VM 110 CNC TRO-GRI-VOU-2008-00001

Name: VOUMARD VM 110 CNC T
Brand: VOUMARD
SKU: RO-GRI-VOU-2008-00001
Price: 13004050 INR
Availability: InStock

Rs. 13,004,050

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used VOUMARD VM 110 CNC T For Sale | gindumac.com

Show in original language

This VOUMARD VM 110 CNC T was manufactured in 2008. A robust internal grinding machine, it features a GE FANUC Series 31i-Model A control, a maximum grinding diameter of 150 mm, and a depth of 80 mm. It supports a longitudinal travel (Z-axis) of 300 mm and a cross travel (X-axis) of 220 mm. Consider the opportunity to buy this VOUMARD VM 110 CNC T internal grinding machine. Contact us for more information.

Overview

brand: VOUMARD
year: 2008
MODEL: VM 110 CNC T
application type: Grinding
Location: Romania
machine type: Internal Grinding Machine
control unit brand: FANUC

Technical Information - VOUMARD VM 110 CNC T

General Data

Measurements width: 1560 mm
Measurements depth: 2000 mm
Measurements height: 2100 mm
Machine weight: 3000 kg

Control Unit

Brand: FANUC
Model: 31i-Model A

Movement

X-AXIS Movement: 220 mm
X-AXIS Rapid traverse: 20000 mm/min
Z-AXIS Movement: 300 mm
Z-AXIS Rapid traverse: 20000 mm/min

Additional Information

Additional equipment

Workpiece spindle motor: 2 kW

Machine Benefits

Technical Machine Benefits

Max. Grinding diameter: 150 mm
Max. Grinding depth: 80 mm
Centre height: 245 mm
Centre height over slide: 130 mm
Number of positions: 4
Air connect: 5 bar
Voltage: 50 hz 3x 400 volt

Extra Information

Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
