TRUMPF - TruPunch 1000 (S19)BA-PUN-TRU-2018-00001

Name: TRUMPF TruPunch 1000 (S19)
Brand: TRUMPF
SKU: BA-PUN-TRU-2018-00001
Price: 22893750 INR
Availability: InStock

Rs. 22,893,750

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Sheet Metal Machinery
➤ Used TRUMPF TruPunch 1000 (S19) For Sale | gindumac.com

Show in original language

This TRUMPF TruPunch 1000 (S19) was manufactured in 2018. It features a closed machine frame, hybrid axis system, and a linear magazine with 20 spots for clamps and tools. Equipped with maintenance-free 3-phase servo motors and a TRUMPF control based on Bosch Rexroth IndraMotion MTX, it offers advanced punching capabilities and efficient operation with only 16,000 work hours. Contact us for more information about this machine.

Overview

brand: TRUMPF
year: 2018
MODEL: TruPunch 1000 (S19)
production hours: 16000
application type: Punching
Location: Bosnia and Herzegovina
machine type: CNC Punching Machine

Technical Information - TRUMPF TruPunch 1000 (S19)

Additional Information

Additional equipment

Precision deburring and roller technology
Smart Punch Monitoring
Parts conveyor belt for part removal flap
Advanced punching equipment

Machine Benefits

Technical Machine Benefits

Recently changed all most important parts (guide, pump), with official service documentation
Serviced with official service throughout its usage
Closed machine frame
Hybrid axis system
Repositioning unit with programmable stripper
Part chute right side
Punching head
Delta drive
Programmable position of the presser foot
Forming // stroke rate punch

Extra Information

Control Unit TRUMPF control based on Bosch Rexroth IndraMotion MTX Control panel with 19" TFT touch screen Integrated technology data Interface Teleservice via internet Automatic shutdown mechanism NC program management Production plan Data transfer USB interface and network connection Network connection RJ45 Central Link Main Drive Drives with maintenance-free 3-phase servo motors Tools Linear magazine with 20 spots for clamps and tools Hydraulic clamps (2 pieces) Foot switch for closing clamps Rotatable single tool adapter Tool length compensation Spray lubrication for punches Vacuum slug removal Function MultiTest Function MultiBend Function tapping with thread counter Part removal flap left side Sensor for part removal flap Additional clamp The Laser cutting technology package is retrofittable Ability for retrofitting the PartMaster Advanced standard configuration 1st index pin position right hand inner side Ball-fitted tables Burr removal by Monitoring of level Sheet collision detection Straightener Compact 240 x 1250 mm Tools and specialized crane for manipulation available for extra cost.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
