Hydraulic injection moulding machine manufactured in 2013. This Negri Bossi 55000H-4250 features a screw diameter of 90 mm and a maximum clamping force of 5500 kN. It offers a real injection volume of 2600 cc and a maximum pressure on material of 1630 bar. If you are looking to get high-quality injection moulding capabilities, consider the Negri Bossi 55000H-4250 machine we have for sale. Contact us for further details.
Overview
- brand: Negri Bossi
- year: 2013
- MODEL: 55000H-4250
- application type: Injection Moulding
- Location: United Kingdom
- machine type: Hydraulic Injection Moulding Machine
Technical Information - Negri Bossi 55000H-4250
Technical Specification
- Clamping Force: 5500 kN
- Screw Diameter: 90 mm
Additional Information
Real injection volume: 2600 cc
Real injection capacity (PS): 2365 g
Plasticification capacity (PS): 105 g/sec
Max. pressure on material: 1630 bar
Max. screw rotation speed: 175 rpm
Screw torque: 4000 Nm
Distance between tie bars: 800 × 900 mm
Platen dimensions: 1260 × 1310 mm
Min / max mould height: 300 – 850 mm
Nozzle forward power: 134 kN
Max. opening stroke: 900 mm
Max. ejector stroke: 300 mm
Ejector force: 125 kN
Pump driving power: 55 kW
Heating power: 34 kW
Total installed power: 89 kW
Additional equipment:
Sytrama robot (currently installed but not included in the advertised machine price; available separately on request)
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
