Yellow CNC plasma cutting machine with two horizontal arms, shown from the front, featuring control panel and cutting bed.
Yellow CNC plasma cutting machine with two horizontal arms, shown from the front, featuring control panel and cutting bed.

MicroStep - MG 6001.25PrGBHU-CUT-MIC-2011-00001

Rs. 1,830,632
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This MicroStep EasyCut 6001.25PrGB was manufactured in 2011. It is a CNC plasma/oxyfuel cutting machine designed for industrial, heavy-duty applications. Features include a large working area of 6000 × 2500 mm, dual-side driven gantry, and compatibility with CAM software like mCAM and AsperWin. It supports up to 6 oxyfuel torches and offers options like automatic height control. Note: the gas console is defective. Contact us for more information about this machine.

Overview

  • brand: MicroStep
  • year: 2011
  • MODEL: MG 6001.25PrGB
  • application type: Cutting
  • Location: Hungary
  • machine type: Plasma Cutting Machine

Additional Information

  • Condition: Out of use for a while; gas console/gas mixer defective (Kjellberg type, last reported by service technician)

  • Working area: 6000 × 2500 mm

  • Cutting technologies: Plasma and/or oxyfuel (can be combined)

  • Max material thickness:

    • Oxyfuel: up to 300 mm

    • Plasma: approx. 35–60 mm (depending on power source, e.g., Hypertherm HPR)

  • Control: MicroStep iMSNC or CyberFab CNC control; compatible with mCAM and AsperWin

  • Operating temperature: –10 °C to +45 °C

  • Multi-torch capability: Up to 2–6 oxyfuel torches possible

  • Machine structure: Dual-side driven gantry for accuracy and repeatability

  • Remarks: Machine not in operation for a long time; gas console fault detected (Kjellberg type)

Additional equipment

  • Plasma power source (e.g., Hypertherm HPR) – determines plasma cutting capacity

  • Oxyfuel equipment: oxyfuel heads/torches (up to 2–6 possible)

  • Plasma cutting head

  • Automatic torch height control

  • Software modules: mCAM (CAM for production prep), AsperWin (automatic nesting)

  • Production system integration (PPS)

  • Gas console/gas mixer (Kjellberg type; currently defective)

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
