This 6s MEI BMW KA1 robot arm was manufactured in 2023. It features a total installed power of 26 kW and operates at a maximum peak air flow of 62.5 liters/min. The machine is equipped with a main control cabinet and various pneumatic components from SMC. If you are looking to get high-quality automation capabilities, consider the MEI BMW KA1 robot arm we have for sale. Contact us for further details.
Overview
- brand: MEI
- year: 2023
- MODEL: BMW KA1
- application type: Robotics
- Location: Germany
- machine type: Robot Arm
Technical Information - MEI BMW KA1
Dimensions
- Machine Height: 2200 mm
- Machine Length: 2300 mm
- Machine Weight: 1200 kg
- Machine Width: 2500 mm
Movement
- Number of Axes: 6
Additional Information
Total installed power: 26 kW
Supply voltage: 400 V AC
Frequency: 50 Hz
Control voltage: 24 V DC
Working voltage: 24 V DC / 220 V AC
Operating pressure: 7 bar
Air consumption per cycle: 5.75 liters (NRA)
Maximum peak air flow: 62.5 liters/min (ANR)
Main control cabinet with PLC
Safety controller
Power supply units
Circuit breakers
Protection switches
Industrial communication switch
Main pneumatic manufacturer: SMC
Cylinders:
SMC MGPM32TF-75Z
SMC MGPM32TF-175Z
SMC CD85N16-50-B
SMC LER50EJ-R5CL17
SMC MXH16-30Z
SMC CDQMB16-30
SMC MHS3-16D
Magnetic sensors:
SMC D-A93SAPC
SMC D-MP025C
Electronic pressure regulator: SMC ITV1050-ILF2
Solenoid valves:
SMC JSY3200-5U
SMC JSY3100-5U
SMC JSY3100R-5U
Mechanical stops: red neoprene M8 (Ref. 507208-M)
Additional equipment
Robot: 6-axis industrial articulated robot
Rotary table: TAKTOMAT RTF650-B-6-1SL90
Gear ratio: 16
Maximum inertia: 46 kgm²
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
