This 6-axis IXION AUERBACH IA2 TLF-1200.4 drilling machine was manufactured in 2004. It features an impressive X-axis travel of 1,200 mm, Y-axis travel of 1,200 mm, and Z-axis travel of 700 mm. The machine includes a robust rotary table surface of 1,000 x 1,000 mm and a maximum workpiece weight capacity of 7,000 kg. If you are looking to get high-quality drilling capabilities, consider the IXION AUERBACH IA2 TLF-1200.4 machine we have for sale. Contact us for further details.
Overview
- brand: IXION
- year: 2004
- MODEL: AUERBACH IA2 TLF-1200.4
- application type: Other Machine Tools
- Location: Germany
- machine type: Drilling Machine (Metal)
- control unit brand: HEIDENHAIN
Technical Information - IXION AUERBACH IA2 TLF-1200.4
Control Unit
- Control Brand: HEIDENHAIN
- Control Model: 430M
Dimensions
- Machine Height: 4020 mm
- Machine Length: 5150 mm
- Machine Width: 5350 mm
Movement
- Number of Axes: 6
- X-axis Travel: 1200 mm
- Y-axis Travel: 1200 mm
- Z-axis Travel: 700 mm
Technical Specification
- Max. Tool Weight: 3.5 kg
- Spindle Power: 18.5 kW
- Spindle Speed: 6000 RPM
- Taper Size: ISO 40
Additional Information
Axes travels:
W (deep hole drilling/milling unit, horizontal): 1,200 mm
A (swiveling deep hole drilling/milling unit): +25° / -15°
B (NC rotary table): 360°
Rotary table: 1,000 x 1,000 mm, 5 T-slots
Max. workpiece weight: 7,000 kg
Max. torque: 115 Nm
Deep drilling capacity:
Max. depth (single pass): 1,200 mm
Diameter range: 3 – 25 mm (up to 36 mm with ELB in reinforced version)
High-pressure coolant system: 100 bar at 42 l/min (upgrade option 001b to 95 l/min)
Tool changer: 24 stations
Max. tool length: 300 mm
Max. tool diameter: 90 mm (160 mm with free adjacent pockets)
Additional equipment
Full enclosure with roof
Oil mist extractor
Chip conveyor
2 traveling steady rests
Deep drilling start package: tool holders and Botek Type 110 tools for various diameters
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
