- ➤ Used Index G 200 RATIO LINE For Sale | gindumac.com
This 5-axis Index G 200 RATIO LINE was manufactured in 2003. It features a Y-axis travel of 120 mm, a main spindle diameter of D65, and a counter spindle diameter of D60. The machine is equipped with a turret that has 12 stations and driven tools on turret 1 and 2. If you are looking to get high-quality turning and milling capabilities, consider the Index G 200 RATIO LINE turn-mill centre we have for sale. Contact us for further details.
Overview
- brand: Index
- year: 2003
- MODEL: G 200 RATIO LINE
- production hours: 92000
- application type: Turning
- Location: Germany
- machine type: Turn-Mill Centre
- control unit brand: SIEMENS
Technical Information - Index G 200 RATIO LINE
Control Unit
- Control Brand: SIEMENS
- Control Model: 840D
Movement
- Number of Axes: 5
Additional Information
C-axis on main and counter spindle
Thread cutting without compensating chuck
Electronic shaft
Additional V24 RS232 interface in control cabinet
Transmit-/Tracyl function
MDE interface (machine on, machine running, parts counter)
Marposs (Brankamp) collision monitoring CMS100
3D machine model for kinematic simulation in CAM programming system
Control cabinet cooling unit
Main spindle D65
Counter spindle D60
Coolant flushing of counter spindle (electrically controlled shut-off valve)
Foot switch
Turret (12 stations) bottom and top
Driven tools on turret 1 and 2
Control function “synchronous tailstock” for turret 2
Y-axis 120 mm
Automatic sliding door (hydraulic)
Coolant pump 80 l / 8 bar
High-pressure coolant connection slide 1 and 2 with solenoid valve
Coolant flushing gun
Preparation for extraction and filter system connection
Operating hours approx. 92,000 h
Additional equipment
Portal unloading device with actuated gripper, NC-controlled
Gripper fingers D4–45 mm and D40–65 mm
Indexed conveyor belt
UNIMAG interface
Chip conveyor (hinged belt), discharge height 1250 mm
Vacuum rotary filter KNOLL (emulsion use)
High-pressure pump 80 bar
Workholding:
Collet chucks for draw tube, HAINBUCH (main and counter spindle)
Power chucks D210 with quick jaw change, Schunk (main and counter spindle)
Stop device
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
