This 3-axis FANUC ROBODRILL α-T14iB was manufactured in 1997. It features an X-axis travel of 500 mm, Y-axis travel of 400 mm, and Z-axis travel of 330 mm. The machine has a maximum spindle speed of 8,000 rpm and a tool changer capacity of 14 tools. If you are looking to get high-quality machining capabilities, consider the FANUC ROBODRILL α-T14iB vertical machining centre we have for sale. Contact us for further details.
Overview
- brand: FANUC
- year: 1997
- MODEL: ROBODRILL α-T14iB
- application type: Milling
- Location: Italy
- machine type: Vertical Machining Centre
- control unit brand: FANUC
Technical Information - FANUC ROBODRILL α-T14iB
Control Unit
- Control Brand: FANUC
- Control Model: Series 16i-M
Dimensions
- Table Load: 250 kg
Movement
- Number of Axes: 3
- X-axis Travel: 500 mm
- Y-axis Travel: 400 mm
- Z-axis Travel: 330 mm
Technical Specification
- Number of Tools: 14
- Spindle Speed: 8000 RPM
- Taper Size: BT 30
Additional Information
Rapid feeds (X/Y/Z): up to 48 m/min
Installed power: 10 kVA
Supply: 200–220 V, 50/60 Hz, 3-phase
Registered cutting time: 15,291 h
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
