➤ Used Estarta 318 MV For Sale | gindumac.com

Show in original language

Cylindrical grinding machine manufactured in 1996. This Estarta 318 MV features a grinding diameter range of 1.5–120 mm and a maximum infeed grinding length of 254 mm. It includes a grinding wheel with dimensions of 610 × 254 × 304.8 mm and a powerful 22 kW drive motor. If you are looking to get high-quality grinding capabilities, consider the Estarta 318 MV machine we have for sale. Contact us for further details regarding this machine.

Overview

brand: Estarta
year: 1996
MODEL: 318 MV
application type: Grinding
Location: Hungary
machine type: Cylindrical Grinding Machine

Technical Information - Estarta 318 MV

Dimensions

Machine Height: 3705 mm
Machine Length: 6485 mm
Machine Weight: 6450 kg
Machine Width: 3140 mm

Movement

Number of Axes: 2

Additional Information

Operating hours: 45,780 h
Refurbished and automated: 2019
Grinding diameter: 1.5–120 mm
Maximum infeed grinding length: 254 mm
Grinding wheel dimensions: 610 × 254 × 304.8 mm
Grinding wheel minimum diameter: 400 mm
Grinding wheel peripheral speed: 35 m/s
Regulating wheel dimensions: 305 × 254 × 127 mm
Regulating wheel speed: 10–250 rpm
Grinding wheel drive motor: 22 kW
Regulating wheel servomotor: 12 Nm
Gross weight: 6,850 kg

Additional equipment

FANUC LR Mate 200iD/7 robot included

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
