Spindle moulder manufactured in 2008. This Colombo AM 60 features a robust design suitable for various woodworking applications. If you are looking to get high-quality woodworking capabilities, consider the Colombo AM 60 spindle moulder we have for sale. Contact us for further details.
Overview
- brand: Colombo
- year: 2008
- MODEL: AM 60
- application type: Profiling
- Location: Denmark
- machine type: Spindle Moulder
Technical Information - Colombo AM 60
Technical Specification
- Spindle Power: 7.5 kW
- Spindle Speed: 3200 RPM
Additional Information
Control: Computer / PLC-controlled
Display: 12" colour LCD-TFT
Interface: RS232
Operating system: Windows
Saw unit – blade diameter: 400 mm
Saw spindle diameter: 30 mm
Saw blade speed: 3,000 rpm
Saw motor power: 3 kW
Tenoning spindle diameter: 50 mm
Effective spindle length: 600 mm
Max. tool diameter: 320 mm
Effective travel: 550 mm
1st profiling spindle diameter: 50 mm
1st profiling spindle effective length: 600 mm
1st profiling spindle max. tool diameter: 200 mm
1st profiling spindle speed: 6,000 rpm
1st profiling spindle motor: 7.5 kW
1st profiling spindle effective travel: 550 mm
2nd profiling spindle diameter: 50 mm
2nd profiling spindle effective length: 600 mm
2nd profiling spindle max. tool diameter: 220 mm
2nd profiling spindle speed: 6,000 rpm
2nd profiling spindle motor: 2.2 kW
2nd profiling spindle effective travel: 550 mm
Glass bead spindle diameter: 35 mm
Glass bead spindle effective length: 20 mm
Glass bead tool diameter: 200 mm
Glass bead spindle motor: 2.2 kW
Tape/feeding carriage speed: 1–80 m/min
Safety enclosure: Sound-insulated safety guarding
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
