Arburg - ALLROUNDER 1200 T 800-70DE-INJ-ARB-2017-00004

Name: Arburg ALLROUNDER 1200 T 800-70
Brand: Arburg
SKU: DE-INJ-ARB-2017-00004
Price: 6698650 INR
Availability: InStock

Rs. 6,698,650

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Plastics Processing Machinery
Used ARBURG ALLROUNDER 1200 T 800-70 - 2017 - Injection moulding machine for sale | gindumac.com

Show in original language

This Arburg ALLROUNDER 1200 T 800 - 70 Injection moulding machine was manufactured in the year 2017 in Germany and has 2090 pump hours. The machine has a clamping force of 800 kN, is in very good condition, and is well maintained. This Injection Moulding Machine is not CE certified and will be sold without CE Certification. It was part of an automation solution in one production cell. Being sold now as single machine it is ideal to integrate in an existing production line. The buyer is responsible for the required CE certification.

Overview

brand: Arburg
year: 2017
MODEL: ALLROUNDER 1200 T 800-70
application type: Injection Moulding
Location: Germany
machine type: Vertical Injection Moulding Machine
availability: Immediately

Technical Information - Arburg ALLROUNDER 1200 T 800-70

General Data

Measurements width: 4360 mm
Measurements depth: 1718 mm
Measurements height: 3085 mm
Machine weight: 7200 kg

Clamping unit

Clamping force: 800 kN

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Screw diameter: 18 mm
- - Injection pressure: 2500 bar
- - Hubvolume [cm^3]: 16
- - L/d ratio screw: 17. 7
- - Max. Mold width [mm]: rotating table diameter 1200 mm
- - Max. Mold height [mm]: 400 (combination with mould stroke)
- - Diameter locating ring(s) [mm]: 125
- - Nose radius: r40
- - Number of cooling circuits: injection: 1, turning table: 3
- - 3 stations turntable // 120 degree right turning

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
