This 3-axis +GF+ AGIE CHARMILLES VCE 800 PRO vertical machining centre was manufactured in 2014. It features a robust HEIDENHAIN iTNC530 control, a maximum spindle speed of 10,000 min/¹, and a tool holder of ISO 40. The work table measures 910x500 mm, supporting up to 1100 kg. Ideal for precision machining, it includes a 24-position tool changer. If you are looking to get high-quality milling capabilities consider the +GF+ AGIE CHARMILLES VCE 800 PRO machine we have for sale. Contact us for further details regarding this machine.
Overview
- brand: +GF+
- year: 2014
- MODEL: AGIE CHARMILLES VCE 800 PRO
- application type: Milling
- Location: Italy
- machine type: Vertical Machining Centre
- availability: Immediately
- control unit brand: HEIDENHAIN
Technical Information - +GF+ AGIE CHARMILLES VCE 800 PRO
General Data
- Machine weight: 5000 KG
Control Unit
- Brand: HEIDENHAIN
- Model: iTNC530
Main drive
- Spindle speed range: 10000 1/MIN
- Spindle motor power: 12 kW
- Tool taper: ISO 40
- Number of axis: 3
Movement
- X-AXIS Movement: 800 mm
- Y-AXIS Movement: 500 mm
- Z-AXIS Movement: 540 mm
Table
- Outer length: 910 mm
- Outer width: 500 mm
- TSlots size: 18 +0.006/ + 0.024 mm
- Number of tslots: 5
- Distance between: 100 mm
- Table load: 1100 kg
Tools
- Slots in storage: 24
- Max weight: 6 kg
Additional Information
- Technical Machine Benefits:
- - Tool holder spindle drive type: toothed belt
- - Torque at 100% ri: 96 nm
- - Tool change time: 6 sec
- - Tightening-loosening times according to vdi 2852: 8 sec
- - Coolant system capacity: 300 l
- - Machine supplied with manuals and ce declaration of conformity
- - Voltage: 50/60 hz
- - Consumption: 32 a
- - Connected load: 16 kw
- - Machine still under power
Machine Benefits
Extra information
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
